Prove it on your water before you build.
A scaled pilot skid runs against your actual feed water, producing real data on recovery, flux, and fouling — so the production system is sized for your conditions, not theoretical assumptions.
Three steps from sample to specification.
Sample & Analyze
We review your feed-water characteristics, variability, and treatment targets to define pilot success criteria.
Pilot on Site
A scaled pilot skid runs against your water, measuring real recovery, flux, and fouling behavior over time.
Design & Build
Pilot data drives the final system design — sized and configured to your validated conditions.
Data you can design — and decide — on.
- ✓ Validated recovery and flux rates on your feed water
- ✓ Fouling behavior and cleaning regime recommendations
- ✓ A production-system design basis grounded in measured performance
- ✓ A clear go/no-go decision before major capital commitment
The Akualys UF Pilot Unit — a complete pilot plant in a 20-ft container.
Delivered, started up, and running on your water. Everything a serious UF pilot needs ships inside one container.
Inside the container
- ✓ 2 × Akualys PVDF UF modules — 861 ft² of membrane area
- ✓ Feed pump & backwash pump
- ✓ Air blower for air scour
- ✓ CEB dosing pumps & daily tanks (NaOCl, NaOH, acid)
- ✓ CIP unit
- ✓ PLC control panel
Measured on your water
- ✓ Feed and filtrate flow (FT 101 / FT 102)
- ✓ Feed and filtrate pressure (PT 101 / PT 102)
- ✓ Filtrate turbidity (AIT 101)
- ✓ Backwash and CEB cycles under real fouling conditions
Full general arrangement and simplified P&ID are included in the pilot unit brochure — download it below.
Akualys UF Pilot Unit — specs, layout & P&ID.
The pilot unit brochure covers the full 20-ft container: equipment list, general arrangement (plan view), and a simplified P&ID. Enter your email and it's yours.
- ✓ Complete equipment list with tags (pumps, blower, tanks, CIP, PLC)
- ✓ General arrangement of the 20-ft container
- ✓ Simplified P&ID showing flow, pressure, and turbidity instrumentation
A pilot format for every stage of decision.
Pilot unit specifications and durations are scoped per project — contact us for details.
Bench-Scale Screening
Initial treatability screening on feed-water samples to confirm UF is the right approach.
Request detailsOn-Site Pilot Skid
A scaled skid operating at your facility for weeks to months, under real operating conditions.
Request detailsDemonstration Unit
Extended demonstration runs for stakeholder validation and operator training before full scale.
Request detailsReady to pilot on your water?
Send us your feed-water characteristics and treatment targets — we'll propose a pilot plan and timeline.
Contact Our Team
